Horizontal Polyurethane Block Sponge Cutting Machine CNC With Knife Belt PLC Control

Horizontal Polyurethane Block Sponge Cutting Machine CNC With Knife Belt PLC Control

    • Horizontal Polyurethane Block Sponge Cutting Machine CNC With Knife Belt PLC Control
    • Horizontal Polyurethane Block Sponge Cutting Machine CNC With Knife Belt PLC Control
  • Horizontal Polyurethane Block Sponge Cutting Machine CNC With Knife Belt PLC Control

    Product Details:

    Place of Origin: Guangdong, China (Mainland)
    Brand Name: ZHMACH
    Certification: CE Certificate
    Model Number: ZHQG-2400A/B

    Payment & Shipping Terms:

    Minimum Order Quantity: one set
    Price: inquiry
    Packaging Details: Foam Block Cutting Machine to be packed in wooden case.
    Delivery Time: 30 days after receive payment
    Payment Terms: Western Union, L/C, T/T
    Supply Ability: two sets per month
    Contact Now
    Detailed Product Description
    Dimension(L*W*H): L2.8*W1.5*H2.5m After-sales Service Provided: Engineers Available To Service Machinery Overseas
    Engineers Available To Service Machinery Overseas: 0-8m/min Control: Automatic PLC Control
    Cutting Protected: Blade Box Cover Protected Voltage: 380V
    Cutting Blade: Knife Blade / Saw Tooth Blade Cutting Setting: Separated Control Box
    Cutting Way: From Left To Right Machine Install: Together With The Automatic Continuously Foaming Machine Line



    Horizontal Polyurethane Block Sponge Cutting Machine with Knife Belt Type / Saw-Toothed Type



    ZHQG-2400A Foam Cutting Machine (knife belt type)

    • digital control
    • Installed on the foam conveyor line
    • for cutting horizontal continuous foam into large pieces
    • Moving left and right

    This machine installed on the foam conveyor line,it is used for continuous foam cut to some length, in order to reansport,storage and processing.This machine adopts digital control,the knife belt is thin and sharp and moving left and right to cut horizontally moved foam,the machine is simple to operate and cut precisely.



    Foam Block Cutting Machine is together with the horizontal continuously foaming machine line to cut the long foam block into the specify length that for other prcess like sheet cutting



    ZHQG-2400A



    Cutting foam height

    2400mm

    Cutting foam width

    1300mm
    Blade frame moving speed
    21m/min

    Conveyer belt speed

    0~8m/mm

    Power

    4.8kw



    ZHQG-2400B Foam Cutting Machine (saw-toothed)

    • digital control
    • Installed on the foam conveyor line
    • for cutting horizontal continuous foam into large pieces
    • The two saw teeth move up and down in high speed to cut foam

    ZHQG-2400B



    Cutting foam height

    2400mm

    Cutting foam width



    1300mm
    Blade frame moving speed
    21m/min

    Conveyer belt speed



    0~8m/mm

    Power

    6.7kw



    Specifications



    Max Foam width for cutting:

    2400mm

    Max Foam height for cutting:

    1400mm

    Min Foam height for cutting:

    500mm

    The Foam density range:

    13kg/m3 to 60kg/m3

    International Standards :

    ISO 40%: 120N-400N

    ASTM Standards:

    ASTM 65%: 300N-1150N

    Cutting Thickness:

    3-400mm

    Cutting Speed:

    0~12m/min

    Position of blade

    -2° to 5°

    Cutter blade type:

    Teeth Blade
    Blade box guide Width:70mm, Thickness: 7mm, Length: over 2600mm

    Blade specification

    Width: 30mm, Thickness: 0.45mm

    Inclined system

    Manual & Automatic

    Total Power:

    5.29kw

    Voltage:

    380V, 50HZ, 3 Phase

    Machine size:

    1500mm*4550mm*3000mm

    Machine weight:

    1500kgs

    Height from conveyor surface to floor:

    800mm
    By default, how many pcs of cutting knife is on the machine already? one
    By default, how many pcs of grinding wheel is on the machine already? two
    By default, how many pcs of Rotary encoder is on the machine already? one

    What is the operation method?

    PLC control

    Key parts and brand

    QHMACH

    PLC

    1PC,SIMENS

    Touch screen

    1PC,SIMENS

    A/C Contactor

    1PC,Panasonic

    Motor

    4PC, Wanxin(Taiwan brand)
    Motor with Gear Reducer 2PC, Wanxin(Taiwan brand)

    Main Electric Parts

    Schneider

    Button & Switch

    Schneider

    Spare parts


      Cutting blade knife (5pcs), Cutting teeth blade ( 5pcs ), Grinding Wheel (10pcs), Rotary encoder (1pc).
    Price Details

    Total Price(FOB USD)

    6800-8800 per set
    (EXW RMB to Port)
    Tax rebate for RMB
    Price until:

    Port

    shenzhen

    Lead time:

    30days after payment
    Payment term:  T/T 30% advance before production.the balance of total amount 70% will be paid before shippment (The bank charge for buyer's account).
    Guarantee: one year
    Packing method disassembled and is wrapped by PE film firstly, then wrapped again by wooden cases.
    Total Volume Packed
    Installation

    Intallation is needed?

    together with production line

    For how many days including Training?

    about 30 days

    How many engineer?

    1-3 engineer

    Engineer speaks English?

    NO

    Visa + Trip cost

    paid by customer
    Fty Info
    Established In 2008
    Website Address http://www.foammachine.en.alibaba.com



    Our Services



    1.  Foam Block Cutting Machine will be independent control by the foam block control box during the foaming need to set the data.

    2. We will help to send engineer to teach how to operate and maintance this machine.

    3. We will send 2-4 experience engineers to install and testing the machines.

    4. We will teach your engineer how to operate the machine and how to maintain the machines.
